350Kw DC Motor Z4-315-12 and matched "Parker" brand DC Drive cabinet were shipped for Singapore on Aug 20,2013

Some information about this DC motor is as below:

Model: Z4-315-12,                                        Rated Power: 350Kw

Speed: 1700/2200RPM,                                Armature voltage: 440Vdc

Field Voltage: 250Vdc                                   Cooling: IC06,with cooling fan & filter

Fan Power: 3phase,415V,50Hz,                    Protection: IP23,

Insulation class H, Temperature rise F            Mounting: B3 (foot mounted),

Duty: S1                                                        Ambient temp. 40oC,

Max. Altitude 1000m                                     Windings & bearings with PT100 for thermal protection

NSK Bearing from Japan                               Encoder: TRD-J1000-RZ
